The VE8001A-V4 Network Page Zone Extender enables voice access to two zones of one-way paging over an IP based LAN/WAN. This allows page zone extension anywhere on the network. Multiple VE8001A-V4 Network Page Zone Extenders can be used on the same network to create very large and distributed public address systems. Example applications include multiple floors in a single building, multiple buildings in a campus environment, city wide paging of all fire and rescue buildings, interstate paging between bank branches.
- Audio Input
- 2 Audio Outputs
- 2 Form C Relays
- 1 Contact Closure Input
- RJ-45 jack for network connection
- Front panel activity LED
- Provides audio for up to 40 Valcom one-way amplified speaker assemblies
- AUX audio input via RCA jack
- Contact closure or VOX operation of audio input
- Removable screw terminal connectors provided for audio and relay interface
- AUX input music mutes during page
- Output control contact closure provided during paging output
- Compatible with 25- or 70-Volt amplifiers
- Barrel jack for optional DC power
- Power over Ethernet 802.3af Compatible
Specifications
Dimensions & Weight
Dimensions: 1.38in H x 6.13in W x 5.25in D(3.50cm x 15.60cm x 13.33cm)
Weight: 1.25 lbs. (0.57 kg)
Shipping Weight: 4.00lbs (1.80kg)
